TFX-5000 Ultrasonic Clamp-on Flow Meter


The Dynasonics® TFX-5000 Ultrasonic clamp-on flow meter is quickly and easily installed without cutting or tapping the pipe. This highly capable meter provides advanced features without breaking your budget.

  • Brand
  • Features
  • Product Certifications
  • Specifications
  • Download


Badger Meter


Simple Clamp-on Design. Streamlined Installation.

The Dynasonics TFX-5000 Ultrasonic clamp-on flow meter reduces installation time and cost because operations can continue during installation, which can be completed in under an hour by a single person.

  • Non-Invasive/Non-Contact. These meters easily attach to a pipe’s exterior and are secured in place without ever penetrating the pipe or coming in contact with the internal liquid. This feature is especially beneficial in settings where the liquid should not be exposed, such as caustic liquids, raw sewage or ultrapure water.
  • Flexible Configuration. Available in a variety of configurations, allowing you to select the meter that’s best for your specific application.
  • Minimal Maintenance. Has no moving parts, which virtually eliminates the need for maintenance or part replacement over the meter’s lifetime.

Product Certifications

CSA ATEX Type Examination Certificate-TFX-5000
CSA ATEX Type Examination Certificate-TFX-5000
CSA CofC Ord Loc TFX-5000
CSA CofC TFX-5000 Ord Loc
CSA CofC TFX-5000 Haz Loc
CSA CofC TFX-5000 Haz Loc



View & Configure CAD/BIM DrawingsDownload CSI Specifications

Showing units in US Customary
  • Size Range
    1/2…48 in.
  • Temperature Range
    -40…350 °F
  • Flow Range
    0.7…33,000 gpm
  • Accuracy
    ± 0.5% ±0.025 ft/s (0.008 m/s)
  • Repeatability
    ± 0.2%
  • Power Supply
    9…28V DC | 20…26 AC | 85…265 AC

View all Specifications
